• 8-MP 1/1.8" CMOS image sensor with low luminance and high-definition image quality
• Outputs max. 8 MP (3840 × 2160) @ 25/30 fps
• Built-in multi-core light, max. IR distance up to 60 m and max. warm light distance up to 60 m
• ROI, SVC, Smart H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, suitable for various bandwidth and storage environments
• Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, suitable for various monitoring scenes
• AI Rule Assist automatically creates highly accurate IVS rules based on Xinghan Vision Models
• With deep learning algorithms, supports AcuPick, video metadata, IVS, face detection, people counting, etc.
• Alarm: 2 in / 2 out; Audio: 1 in / 1 out; RS-485; supports max. 1 TB Micro SD card; built-in dual microphones; 1-channel speaker; supports two-way talk
• 12 VDC / PoE power supply; ePoE support; 12 VDC power output with max. current 165 mA; easy installation
• IP67 and IK10 protection; supports window heating

Camera
• Image Sensor: 1/1.8" CMOS
• Max. Resolution: 3840 (H) × 2160 (V)
• ROM: 4 GB
• RAM: 2 GB
• Scanning System: Progressive
• Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
• Min. Illumination:
     – 0.0006 lux@F1.2 (Color, 30 IRE)
     – 0.0003 lux@F1.2 (B/W, 30 IRE)
     – 0 lux (Illuminator on)
• S/N Ratio: >56 dB
• Illumination Distance:
     – Up to 60 m (IR)
     – Up to 60 m (Warm light)
• Illuminator On/Off Control: Auto; Manual; Zoomprio
• Illuminator Number: 4 (Multi-core (IR + warm) light)
• Angle Adjustment:
     – Pan: 0°–360°
     – Tilt: 0°–90°
     – Rotation: 0°–360°

Lens
• Lens Type: Motorized vari-focal
• Lens Mount: φ16
• Focal Length: 2.7 mm–12 mm
• Max. Aperture: F1.2
• Field of View:
     – H: 98°–48°
     – V: 52°–27°
     – D: 117°–55°
• Iris Control: Auto
• Iris Control Type: P-Iris
• Close Focus Distance: 0.16 m (0.53 ft)

DORI Distance
• Wide (W):
     – Detect: 96.6 m
     – Observe: 38.6 m
     – Recognize: 19.3 m
     – Identify: 9.6 m
• Tele (T):
     – Detect: 186.6 m
     – Observe: 74.6 m
     – Recognize: 37.3 m
     – Identify: 18.7 m
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4). The numbers do not reflect intelligent function distances.

Intelligence
• EPTZ: Yes
• IVS (Perimeter Protection):
     – Intrusion, tripwire, fast moving (support classification and accurate detection of vehicle, animal and human)
     – Loitering detection, people gathering, parking detection, stay detection
     – Perimeter Protection Large-Scale AI Models to extend detection range and reduce false alarms
     – Supports self-learning to filter false alarms
• SMD: SMD 4.0
• AcuPick:
     – Uses deep learning algorithms
     – Works with back-end devices
     – Accurate matching of people, animal and motor vehicles
     – Fast search in live and recorded video
• Face Detection:
     – Face detection and snapshot
     – Snapshot optimization and optimal face snapshot upload
     – Face enhancement and face exposure
     – Face attribute extraction (6 attributes, 8 expressions)
     – Face snapshot formats: face, one-inch photo or custom
     – Snapshot strategies: real-time, quality priority, optimization snapshot
     – Face angle filter and optimization time setting
• People Counting:
     – Tripwire people counting with report export (day/week/month/year)
     – Area people counting and queue management with report export (day/week/month)
     – Up to 4 rules for tripwire, area counting and queue management
• Heat Map: Yes
• Video Metadata:
     – Motor vehicle, non-motor vehicle, face and human body detection
     – Snapshot and snapshot optimization
     – Optimal face snapshot upload
     – Vehicle attribute extraction (6 attributes for motor vehicle, 6 for non-motor vehicle)
     – Face and human body attribute extraction (6 face attributes, 8 human body attributes)
• Smart Search:
     – Works with Smart NVR
     – Supports refined intelligent search, event extraction and event video merging

Video
• Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (sub stream only)
• AI Coding: AI H.265; AI H.264; Includes Smart H.265+ and Smart H.264+
• Video Frame Rate:
     – Main stream: 3840 × 2160 @(1–25/30 fps)
     – Sub stream: 704 × 576 @(1–25 fps) / 704 × 480 @(1–30 fps)
     – Third stream: 1920 × 1080 @(1–25/30 fps)
     – Fourth stream: 1280 × 720 @(1–25/30 fps)
Frame rates listed are maximum per stream; multiple streams are subject to total encoding capacity.
• Streaming Capability: 4 streams
• Resolution:
     – 8M (3840 × 2160)
     – 6M (3072 × 2048 / 3200 × 1800)
     – 5M (3072 × 1728 / 2592 × 1944 / 2960 × 1668)
     – 4M (2688 × 1520 / 2560 × 1440)
     – 3M (2048 × 1536 / 2304 × 1296)
     – 1080p (1920 × 1080)
     – 1.3M (1280 × 960)
     – 720p (1280 × 720)
     – D1 (704 × 576 / 704 × 480)
     – VGA (640 × 480)
     – CIF (352 × 288 / 352 × 240)
• Bit Rate Control: VBR; CBR
• Video Bit Rate:
     – H.264: 3 kbps–16384 kbps
     – H.265: 3 kbps–16384 kbps
• Day/Night: Auto (ICR) / Color / B/W
• BLC: Yes
• HLC: Yes
• WDR: 130 dB
• Scene Self-adaptation (SSA): Yes
• White Balance: Auto; natural; street lamp; outdoor; manual; regional custom
• Gain Control: Auto / Manual
• Noise Reduction: 3D NR
• Motion Detection: OFF / ON (4 areas, rectangular)
• Region of Interest (RoI): Yes (4 areas)
• Image Stabilization: Electronic Image Stabilization (EIS)
• Smart Illumination: Yes
• Smart Dual Light: Yes
• Defog: Yes
• Image Rotation: 0° / 90° / 180° / 270°
     – Supports 90° / 270° with 4M (2688 × 1520) resolution and lower
• Mirror: Yes
• Privacy Masking: 4 mosaics or 8 color blocks
• LDC: Yes

Audio
• Built-in MIC: Yes, built-in dual Mic
• Built-in Speaker: Yes, built-in speaker
• Audio Compression: G.711a; G.711Mu; PCM; G.726; G.723

Alarm
• Alarm Event:
     – No SD card; SD card full; SD card error
     – Network disconnection; IP conflict; illegal access
     – Motion detection; video tampering
     – Tripwire; intrusion; fast moving; loitering detection
     – People gathering; parking detection; scene changing
     – Audio detection; voltage detection; external alarm
     – Face detection; video metadata; SMD
     – People counting (area, stay detection, queue people number, queue time)
     – Security exception; defocus detection

Network
• Network Port: RJ-45 (10/100 Base-T)
• SDK and API: Yes
• Network Protocol:
     – IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP
     – SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP
     – Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P
     – Auto Registration
• Interoperability: ONVIF (Profile S / G / T / M); CGI
• User/Host: 20 (Total bandwidth: 80 M)
• Storage: FTP; SFTP; Micro SD card (max. 1 TB); NAS
• Browser:
     – IE 11 and later
     – Chrome 102 and later
     – Firefox 88 and later
• Management Software: DSS; DMSS; DoLynk Care
• Mobile Client: iOS; Android
• Security:
     – Digest; WSSE; account lockout; security logs
     – IP/MAC filtering
     – X.509 certificate generation and import
     – Syslog; HTTPS; 802.1x
     – Trusted boot; trusted execution; trusted upgrade
     – Session security; security warning

Function
• Defog (Glass Heating):
     – Window heating quickly removes water, ice, snow and mist to keep images clear
• Light Warning:
     – Warm light warning
     – Flash / solid on duration: 5 s–30 s
     – Flash frequency: high; medium; low
• Sound Warning:
     – 11 built-in sound alarms
     – Supports importing 10 custom sound alarms
     – Sound level: 0–100
     – Play times: 1–10

Certification
• Certifications:
     – CE-LVD: EN62368-1
     – CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Port
• RS-485: 1 (baud rate: 1200 bps–115200 bps)
• Audio Input: 1 channel (RCA port)
• Audio Output: 1 channel (RCA port)
• Alarm Input:
     – 2 channels in: wet contact, 5 mA 3–5 VDC
• Alarm Output:
     – 2 channels out: dry contact, 1,000 mA 30 VDC / 500 mA 50 VAC
• Power Output:
     – 12 VDC power output
     – Max. current 165 mA
     – Peak current 700 mA

Power
• Power Supply: 12 VDC (±30%); PoE+ (802.3at); ePoE
• Dual Power Backup:
     – When power adapter and PoE supply power simultaneously, one is disconnected
     – Device continues operating without restart
• Power Consumption:
     – Basic: 5.3 W (12 VDC); 6.4 W (PoE)
     – Max. (IR on + siren and light active deterrence + intelligence on + glass heating):
     – 21.3 W (12 VDC)
     – 24.2 W (PoE)
     – Heating: 3.2 W (12 VDC); 3.6 W (PoE)
• ePoE: Yes

Environment
• Operating Temperature: –40 °C to +60 °C
• Operating Humidity: ≤95% (RH), non-condensing
• Storage Temperature: –40 °C to +60 °C (–40 °F to +140 °F)
• Storage Humidity: ≤95% (RH), non-condensing
• Protection: IP67; IK10
• Anti-corrosion Level: Basic Protection

Structure
• Casing Material: Metal
• Product Dimensions: 302.6 mm × 110.8 mm × 99.1 mm (L × W × H)
• Net Weight: 1.65 kg
• Gross Weight: 2.21 kg
