> 8-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@20 fps, and supports 4 MP (2688 × 1520)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light, and the max. illumination distance is 30 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Supports max. 256 G Micro SD card; built in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD Plus

Camera
Image Sensor: 1/1.8" CMOS
Max. Resolution: 3840 (H) × 2160 (V)
ROM: 128 MB
RAM: 256 MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Min. Illumination: 0.0008 lux@F1.0
S/N Ratio: >56 dB
Illumination Distance: Up to 30 m (Warm light)
Illuminator On/Off Control: Auto; Manual
Illuminator Number: 2 (Warm light)
Angle Adjustment:
Pan: 0° – 360°
Tilt: 0° – 78°
Rotation: 0° – 360°

Lens
Lens Type: Fixed-focal
Lens Mount: M16
Focal Length: 2.8 mm
Max. Aperture: F1.0
Field of View:
H: 110°; V: 59°; D: 131°
Iris Control: Fixed
Close Focus Distance: 2.8 m

DORI Distance
Detect: 84.0 m
Observe: 33.6 m
Recognize: 16.8 m
Identify: 8.4 m
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Intelligence
IVS (Perimeter Protection): Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
SMD: SMD Plus
Smart Search: Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video
Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec: Smart H.265+; Smart H.264+
Video Frame Rate:
Main stream: 3840 × 2160@(1–20 fps) / 2688 × 1520@(1–25/30 fps)
Sub stream: 704 × 576@(1–25 fps) / 704 × 480@(1–30 fps)
The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Streaming Capability: 2 streams
Resolution:
8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728 / 2880 × 1620);
4M (2688 × 1520); 3M (2048 × 1536 / 2304 × 1296);
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720);
D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240)
Bit Rate Control: VBR; CBR
Video Bit Rate:
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night: Color / B/W
BLC: Yes
HLC: Yes
WDR: 120 dB
White Balance: Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control: Auto / Manual
Noise Reduction: 3D NR
Motion Detection: OFF / ON (4 areas, rectangular)
Region of Interest (RoI): Yes (4 areas)
Smart Illumination: Yes
Image Rotation: 0° / 90° / 180° / 270° (Support 90° / 270° with 2688 × 1520 resolution and lower)
Mirror: Yes
Privacy Masking: 4 areas
LDC: Yes

Audio
Built-in MIC: Yes, built-in Mic
Audio Compression: G.711a; G.711Mu; PCM; G.726

Alarm
Alarm Event: No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception

Network
Network Port: RJ-45 (10/100 Base-T)
SDK and API: Yes
Network Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration
Interoperability: ONVIF (Profile S & Profile G & Profile T); CGI
User/Host: 20 (Total bandwidth: 48 M)
Storage: FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser: IE; Chrome; Firefox
Management Software: Smart PSS Lite; DSS; DMSS
Mobile Client: iOS; Android
Security:
Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade; Session security; Security warning

Certification
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Power
Power Supply: 12 VDC (±30%); PoE (802.3af)
Power Consumption:
Basic: 2.4 W (12 VDC); 3 W (PoE)
Max.: 5.6 W (12 VDC); 6.4 W (PoE) (H.265+ intelligence on + WDR + illuminator intensity)

Environment
Operating Temperature: –40 °C to +60 °C
Operating Humidity: ≤95% (RH), non-condensing
Storage Temperature: –40 °C to +60 °C
Storage Humidity: ≤95% (RH), non-condensing
Protection: IP67

Structure
Casing Material: Inner core: Metal; Cover: Plastic
Product Dimensions: 109.5 mm × Φ109.9 mm
Net Weight: 0.42 kg
Gross Weight: 0.59 kg
