> Panorama: Outputs 180° wide angle splicing image
> Detail: 1/2.8"4Megapixel STARVIS™ CMOS
> 10x optical zoom
> Starlight technology
> Max. 25/30 fps@8M
> IR distance up to 70 m
> Warm light illumination distance up to 30 m
> Active deterrence
> Auto Tracking Lite
> Perimeter protection
> Face detection
> SMD4.0
> IP66
> Smart dual light

Camera
• Image Sensor:
– Overview channel: 1/2.8" CMOS
– Detail channel: 1/2.8" CMOS
• Pixel:
– Overview channel: 8 MP
– Detail channel: 4 MP
• Max. Resolution:
– Overview channel: 5376 (H) × 1520 (V)
– Detail channel: 2560 (H) × 1440 (V)
• ROM:
– Overview channel: 4 GB
– Detail channel: 4 GB
• RAM:
– Overview channel: 2 GB
– Detail channel: 1 GB
• Electronic Shutter Speed:
– Overview channel: 1 s–1/100,000 s
– Detail channel: 1 s–1/30,000 s
• Scanning System: Progressive
• Min. Illumination:
– Overview channel:
– 0.005 lux@F1.6 (Color, 30 IRE)
– 0.0005 lux@F1.6 (B/W, 30 IRE)
– 0 lux (illuminator on)
– Detail channel:
– 0.005 lux@F1.6 (Color, 30 IRE)
– 0.0005 lux@F1.6 (B/W, 30 IRE)
– 0 lux (illuminator on)
• Illumination Distance:
– Overview channel:
– 30 m (98.43 ft) (IR)
– 30 m (98.43 ft) (white light)
– Detail channel:
– 70 m (229.66 ft)
– 30 m (98.43 ft) (white light)
• Illuminator On/Off Control:
– Overview channel: Manual; Auto; Off
– Detail channel: Zoom Prio; Manual; Auto; Off
• Illuminator Number:
– Overview channel: 2 (IR light); 2 (white light)
– Detail channel: 2 (Dual light fusion); 2 (IR light)

Lens
• Focal Length:
– Overview channel: 2.8 mm
– Detail channel: 4 mm–40 mm
• Max. Aperture:
– Overview channel: F1.6
– Detail channel: F1.6–F3.6
• Field of View:
– Overview channel: H: 180°; V: 47°
– Detail channel:
– H: 58°–11.3°
– V: 33.1°–6.4°
– D: 66.4°–12.8°
• Optical Zoom:
– Overview channel: NA
– Detail channel: 10×
• Focus Control: Auto; manual; semi-auto
• Close Focus Distance:
– Overview channel: 0.6 m
– Detail channel: 0.1 m–0.5 m
• Iris Control:
– Overview channel: NA
– Detail channel: NA

DORI Distance
• Detect: 500 m
• Observe: 197.5 m
• Recognize: 100 m
• Identify: 50 m
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4). The numbers do not reflect intelligent function distances.

PTZ
• Pan/Tilt Range:
– Pan: 0° to 345°
– Tilt: –10° to +90°
• Manual Control Speed:
– Overview channel: NA
– Detail channel: H: 0.1°–80°/s; V: 0.1°–50°/s
• Preset Speed: H: 80°/s; V: 50°/s
• Preset: 300
• Tour: 8 (up to 32 presets per tour)
• Power-off Memory: Yes
• Idle Motion: Preset; Tour

Intelligence
• IVS (Perimeter Protection): Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human/vehicle alarm classification; linkage tracking (only for people)
• Face Detection:
– Detail channel supports face detection, optimization, snapshot capturing and uploading high-quality face images
– Attribute extraction: 6 attributes, 8 expressions
– Face cutout supported (custom one-inch photo size)
– Snapshot modes: real-time, quality first, preferred image selection
• Auto Tracking: Auto Tracking Lite
• Smart Tracking:
– WizTracking (Xinghan large-scale AI models-driven) human tracking
– Relay tracking (X-SPANS series only): continues after target exits overview channel
– Linkage tracking (X-SPANS series only): tracks targets visible in overview channel only
• Auto Patrol:
– Links up to 5 presets or scan after IVS alarm
– IVS and SMD can be enabled simultaneously
• SMD: Yes
• AcuPick:
    – Deep learning target matching with backend devices
    – Supports people and motor vehicles
    – Live and recorded video search
    – Overview channel support
• Active Deterrence:
    – Light Warning: red and blue light; flash duration 5 s–30 s; frequency high/medium/low
    – Sound Warning:
    – 11 built-in alarms
    – 10 custom sounds importable
    – Volume adjustable 0%–100%
    – Play times: 1–10

Video
• Video Compression: H.264H; H.264B; Smart H.265+; H.265; Smart H.264+; H.264M; MJPEG (Sub Stream 1)
• Streaming Capability: 3 streams
• Resolution:
    – Overview channel: 5376 × 1520; 2688 × 752; 1080p; 720p; 1344 × 368; D1; CIF
    – Detail channel: 2560 × 1440; 3M; 1080p; 1.3M; 720p; D1; CIF
• Video Frame Rate:
    – Overview channel:
        – Main stream: 5376 × 1520 @(1–25/30 fps)
        – Sub stream 1: 1344 × 368/D1/VGA/CIF @(1–25/30 fps)
        – Sub stream 2: 2688 × 752/1080p/1.3M/720p @(1–25/30 fps)
    – Detail channel:
        – Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps)
        – Sub stream 1: D1/VGA/CIF @(1–25/30 fps)
        – Sub stream 2: 1080p/1.3M/720p @(1–25/30 fps)
• Bit Rate Control: CBR / VBR
• Video Bit Rate:
    – Overview channel: H.264 128 kbps–16,384 kbps; H.265 51 kbps–13,312 kbps
    – Detail channel: H.264 96 kbps–16,384 kbps; H.265 38 kbps–10,240 kbps
• Day/Night:
    – Overview channel: Auto; Color; B/W
    – Detail channel: Auto; Color; B/W; Electronic
• BLC: Yes
• WDR:
    – Overview channel: DWDR
    – Detail channel: 120 dB
• HLC: Yes
• White Balance:
    – Overview channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
    – Detail channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
• Gain Control:
    – Overview channel: Auto; manual; gain prio
    – Detail channel: Auto; manual; gain prio
• Noise Reduction:
    – Overview channel: 2D NR; 3D NR
    – Detail channel: 2D NR; 3D NR
• Motion Detection: Yes
• Region of Interest (RoI): Yes
• Image Stabilization:
    – Overview channel: NA
    – Detail channel: Electronic Image Stabilization (EIS)
• Defog:
    – Overview channel: Electronic
    – Detail channel: Electronic
• Digital Zoom:
    – Overview channel: NA
    – Detail channel: 16×
• Image Rotation:
    – Overview channel: NA
    – Detail channel: 180°
• S/N Ratio:
    – Overview channel: ≥55 dB
    – Detail channel: ≥55 dB

Audio
• Audio Compression:
    – Overview channel: PCM; G.711A; G.711Mu; G.726; MPEG2-Layer2; G.722.1; G.729
    – Detail channel: NA
• Privacy Masking:
    – Up to 24 areas
    – Max. 8 areas per view
    – Multiple colors and mosaic supported

Network
• Network Port: RJ-45 (100 Base-T)
• Network Protocol: FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; QoS; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; RTSP; ARP
• Interoperability: ONVIF (Profile S / G / T); CGI; SDK; P2P
• Streaming Method: Unicast / Multicast
• User/Host: 20 (total bandwidth: 64 M)
• Storage: Micro SD card (512 GB); FTP/SFTP; NAS
• Browser: web5.0 (IE 9+, Chrome 41+, Firefox 50+, Safari 10+)
• Management Software: DMSS; DSS Pro
• Mobile Client: iOS; Android

Certification
• Certifications: CE – EN55032 / EN55035 / IEC61000-3-2 / IEC61000-3-3 / EN62368-1 / IEC62471

Port
• Audio Input: 1 channel (LINE IN, bare wire, built-in mic – mutually exclusive)
• Audio Output: 1 channel (LINE OUT, bare wire, built-in speaker – mutually exclusive)
• Alarm Input: 1 (on-off value input: 0–5 VDC)
• Alarm Output: 1 channel
• Alarm Linkage: Capture; recording; send email; preset; alarm digital output; audio; warning light
• Alarm Event: Motion/tampering; network disconnection; IP conflict; memory card state; memory space detection

Power
• Power Supply: 12 VDC, 3 A ±10%; PoE+ (802.3at)
• Power Consumption: Basic: 12 W, Max: 25 W (illuminator + heating glass + siren + light active deterrence + PTZ)

Environment
• Operating Temperature: –30 °C to +60 °C
• Operating Humidity: ≤95%
• Protection: TVS 6000 V lightning proof; IP66; surge protection; voltage transient protection

Structure
• Product Dimensions: 140.3 mm × 181.7 mm × 238.8 mm (L × W × H)
• Net Weight: 2.17 kg
• Gross Weight: 3.1 kg
